API Payment Notification

Overview

Service to send a notification from Manjo to the Merchant system regarding the payment status of a transaction.

Direction: Manjo to Merchant
Version: 1.0
Service Code: 52
HTTP Method: POST
Path: ../v1.0/qr/qr-mpm-notify

---

Request Structure

HTTP Headers

Field	Attribute	Type	Description	Example
Content-Type	M	String	Media type of resource	application/json
Authorization	C	String	Access token with Bearer format	Bearer eyJhbGciOi...
X-TIMESTAMP	M	String	Client's local timestamp (yyyy-MM-ddTHH:mm:ssTZD)	2020-01-15T17:01:11+07:00
X-SIGNATURE	M	String	HMAC_SHA512 signature using clientSecret	85be817c55b2c13...
ORIGIN	O	String	Merchant domain	www.hostname.com
X-IP-ADDRESS	M	String	IP Address of the sender	172.24.281.24
X-PARTNER-ID	M	String(36)	Unique ID for a partner	821508239190406...
X-EXTERNAL-ID	M	String(36)	Unique reference number per day	418075935899...
CHANNEL-ID	M	String(5)	Device identification (Use "05")	95221

X-SIGNATURE Formula:

stringToSign = HTTPMethod + ":" + EndpointUrl + ":" + AccessToken + ":" + Lowercase(HexEncode(SHA256(minify(RequestBody)))) + ":" + TimeStamp
signature = HMAC_SHA512(clientSecret, stringToSign)

Request Body

{
	"referenceNo": "A0000001702",
	"originalPartnerReferenceNo": "DIRECT-API-NMS-6giumc6rde",
	"transactionStatus": "00",
	"transactionStatusDesc": "Success",
	"customerNumber": "08123456789",
	"accountType": "10",
	"destinationAccountNumber": "1234567890",
	"destinationAccountName": "Merchant Name",
	"amount": {
		"value": "10000.00",
		"currency": "IDR"
	},
	"externalStoreId": "STORE-001",
	"additionalInfo": {
		"trxAmount": "10000.00",
		"tips": "0.00"
	},
	"custName": "John Doe",
	"acqName": "Bank ABC",
	"issuerName": "Bank XYZ",
	"rrn": "000000123456",
	"TrxTime": "20250101123059"
}

Parameter Details

Parameter	Attribute	Type	Description
referenceNo	M	String(64)	Transaction identifier on service provider system
originalPartnerReferenceNo	M	String(64)	Transaction identifier on merchant system (partner reference)
transactionStatus	M	String(2)	Status of transaction code. 00 = Success 03 = Paid 04 = Pending 05 = Refunded 06 = Cancelled 01 = Failed 02 = Not Found
transactionStatusDesc	O	String(100)	Description status transaction
customerNumber	O	String(64)	Customer Account Number
accountType	O	String(2)	Type of customer account (saving, current/giro, credit, wallet, unspecified)
destinationAccountNumber	O	String(25)	Destination account number
destinationAccountName	O	String(25)	Destination account name
amount	O	Object	Amount Object
amount.value	M	String(16,2)	Net amount of transaction (2 decimal digits)
amount.currency	M	String(3)	Currency (ISO4217)
externalStoreId	O	String(25)	External Store ID
additionalInfo	O	Object	Additional Information Object
additionalInfo.trxAmount	M	String(16,2)	Net amount of the transaction (2 decimal digits)
additionalInfo.tips	M	String(16,2)	Tips amount (2 decimal digits)
custName	M	String(36)	Customer/Issuer Name
acqName	M	String(36)	Name Acquirer (Manjo)
issuerName	M	String(25)	Issuer Name
rrn	M	String(25)	Retrieval Reference Number
TrxTime	M	String(16)	Transaction date time (yyyyMMddHHmmss)

---

Error Codes

HTTP Code	Service Code	Case Code	Message	Category	Description
200	52	00	Success	Successful	Success
400	52	01	Invalid Field Format {field name}	Message	Invalid format
400	52	02	Invalid Mandatory Field {field name}	Message	Missing or invalid format of mandatory field headers or body
401	52	00	Unauthorized {reason}	System	General unauthorized error. Possible reasons: invalid signature, invalid client key
401	52	01	Invalid token	System	Token found in request is invalid (Access Token Not Exist, Access Token Expiry)
409	52	00	Conflict	System	Cannot use same X-EXTERNAL-ID in same day

---

Implementation Examples

Example Request (cURL)

curl -X POST \
  'https://api.manjo.com/v1.0/qr/qr-mpm-notify' \
  -H 'Content-Type: application/json' \
  -H 'Authorization: Bearer <ACCESS_TOKEN>' \
  -H 'X-TIMESTAMP: 2025-01-15T17:01:11+07:00' \
  -H 'X-SIGNATURE: <CALCULATED_SIGNATURE>' \
  -H 'X-PARTNER-ID: 821508239190...' \
  -H 'X-EXTERNAL-ID: 418075935899...' \
  -H 'CHANNEL-ID: 95221' \
  -d '{
    "referenceNo": "A0000001702",
    "originalPartnerReferenceNo": "ORD-12345",
    "transactionStatus": "00",
    "amount": {
        "value": "50000.00",
        "currency": "IDR"
    },
    "custName": "Budi Santoso",
    "acqName": "Manjo",
    "issuerName": "Bank BCA",
    "rrn": "123456789012",
    "TrxTime": "20250115170111",
    "additionalInfo": {
        "trxAmount": "50000.00",
        "tips": "0.00"
    }
}'

---

Important Notes

1. Response Code Structure: httpcode(3) + servicecode(2) + casecode(2).
2. Date Format: Timestamps in headers use ISO 8601 (yyyy-MM-ddTHH:mm:ssTZD), while TrxTime in body uses yyyyMMddHHmmss.
3. Currency: Amounts for IDR must include 2 decimal places (e.g., 10000.00).
